IEE's CAN Bus Keypads' compliance to key Military Standards enable them to be used in combat vehicle crew station applications that have not been possible before. This innovation helps vehicle integrators create ergonomic work stations to manage the increasingly complex demands on the crew.
Military vehicle crew stations continue to evolve into integrated, mission-management workstations where small crews can oversee sensors, weapons, robotic teammates and autonomous platforms simultaneously. IEE CAN Bus Keypads support the Modular Open Systems Approach (MOSA) for ease of integration and optimal crew station functionality.
These crew stations now include multiple screens placed close together to provide continuous video and graphic imagery to the warfighter. The CAN Bus Keypads enable system integrators to position function keys and indicators near, but not between the screens, thus preserving ergonomics for the warfighter.
Features:
• 2x4 Keypad
• 8 sealed snap dome push buttons
• Dimmable backlight and LED indicators
• Control Interface: Controller Area Network (CAN) module
--Standard Compliance SAE-J1939; Full CAN Specification 2.0B compliance
• MIL-STD-1472H Human Factors
• MIL-STD-810H Environmental
• MIL-STD-461G EMI/EMC
• MIL-STD-1275F Power
• MIL-STD-3009 NVIS (option)
• Lightweight, rugged sealed and vented enclosure fit for use in military ground vehicle and airborne applications
